可定制化耐切割耐磨损超高柔性超高寿命耐油耐腐蚀耐候性
|
芯线数和导体标称截面积 |
芯线外径 |
电缆外径 |
导体直流阻抗 |
绝缘阻抗 |
成品允许电流 |
|
㎜2 |
mm |
mm |
Ω/KM |
MΩ·KM |
A |
|
3C0.15(26AWG) |
0.9 |
4.2 |
138.3 |
50 |
3.9 |
|
4C0.15(26AWG) |
0.9 |
4.5 |
138.3 |
3.5 |
|
|
3C0.2(24AWG) |
1.1 |
4.7 |
98.8 |
4.9 |
|
|
4C0.2(24AWG) |
1.1 |
5.0 |
98.8 |
4.4 |
|
|
7C0.2(24AWG) |
1.1 |
5.6 |
98.8 |
3.6 |
|
|
12C0.2(24AWG) |
1.1 |
7.1 |
98.8 |
3.1 |
|
|
18C0.2(24AWG) |
1.1 |
8.0 |
98.8 |
2.7 |
|
|
25C0.2(24AWG) |
1.1 |
9.3 |
98.8 |
2.4 |
|
|
7C0.35(22AWG) |
1.45 |
6.9 |
59.3 |
5.0 |
|
|
12C0.35(22AWG) |
1.45 |
8.5 |
59.3 |
4.3 |
|
|
18C0.35(22AWG) |
1.45 |
9.8 |
59.3 |
3.7 |
|
|
25C0.35(22AWG) |
1.45 |
11.5 |
59.3 |
3.4 |
