可定制化多重认证抗干扰
|
芯线数和导体标称截面积 |
芯线外径 |
电缆外径 |
导体直流阻抗 |
绝缘阻抗 |
成品允许电流 |
|
mm2 |
mm |
mm |
Ω/KM |
MΩ·KM |
A |
|
4E0.75+2C0.5 |
2.0/1.6 |
7.8 |
25.2/37.8 |
50 |
9.7/7.9 |
|
4E1.0+2C0.75 |
2.2/2.0 |
8.5 |
18.9/25.2 |
11.6/9.9 |
|
|
4E1.5+2C0.75 |
3.0/2.0 |
10.5 |
12.7/25.2 |
19.6/10.6 |
|
|
4E2.5+2C1.0 |
3.7/2.5 |
12.7 |
7.6/18.9 |
21.2/13.2 |
|
|
4E4+2C1.5 |
4.2/3.0 |
14.4 |
4.7/12.7 |
33.4/16.8 |
|
|
4E6+2C1.5 |
4.8/3.0 |
15.5 |
3.3/12.7 |
41.2/17.1 |
|
|
4E10+2C1.5 |
6.1/3.0 |
18.8 |
1.9/12.7 |
57.5/17.9 |
|
|
4E16+2C1.5 |
7.2/3.0 |
21.1 |
1.2/12.7 |
75.7/18.4 |
|
|
4E25+2C1.5 |
9.6/3.0 |
26.5 |
0.76/12.7 |
82.2/19.3 |
